SP108E (V2) controller for led strips with dynamic effects - Wifi and voice assistants Google and Alexa
Ref : CTRLSP108E [#136]Controller for Magic led strips (dynamic effects) 5, 12 and 24V, WiFi and Google and Alexa voice assistants.
Control by IoS and Android application.
180 modes available, variable speed, colors and light intensity, easy to use.
Products guaranteed for 3 or 5 years
Return within 14 days
Characteristics - Selection criteria
Strip type : | Dynamic effects |
Controller type : | WiFi |
Multi zones : | No |
Voice assistants : | Google Home and Alexa |
SP108E WiFi controller for led strips with dynamic effects (Magic) 5, 12 and 24V.
It can control up to 2048 pixels.
Warning: The controller has a power of 100W and can only power one 5 meter strip. It is possible to chain several other ribbons to obtain a continuous dynamic effect, but it is essential to supply the additional ribbons with 12V, by connecting them each to the 12V power supply.
The controller works via Wifi with the Ledshop app available in Apple store or Google play.
In addition to controls="controls"ng LED lighting, it offers multiple animation functions from among 180 available modes, meteor, breathing, wave, catch-up, stack, flash, flow, static.
The application can only drive one controller at a time.
The controller can be paired with a switch because it memorizes the state it was in before switching off. When switched on again, the program initially in progress will resume.
It is not waterproof and must be used away from splashing water or excessive humidity.
The device can drive Magic led strips of type WS2811, WS2812B, WS2815, WS2801, SK6812, WS2813, SK9822, APA102, WS2818, LPD6803, LPD8806, TM1913, UCS1903, SM16703.
Input voltage | 5, 12 or 24V DC |
Output voltage | 5, 12 or 24V DC |
Output current | 8A max |
Power | 100W max |
Sealing | Not waterproof IP20 |
Signal | 2.4 GHz Wifi (not compatible with 5 GHz Wifi) |
Wifi Distance | about 30 meters |
Piloting | WS2811, WS2812B, WS2815, WS2801, SK6812, WS2813, SK9822, APA102, WS2818, LPD6803, LPD8806, TM1913, UCS1903, SM16703 |
Number of pixels | 2048 |
Command | WiFi 2.4GHz |
App | Ledshop |
OS | Android 4.4 or ISO 10.0 |
Controller dimensions | 85x45x22mm |
Temperature range | -20 to 60°C |
Weight | 40 grams |
Certifications | CE, RoHS |
Warranty | 3 years |
